220v to 3.3V 1w
220v to 3.3V 1w
Wide lnput Voltage :85-264VAC or 110-370VDC
lsolation voltage: 2500VAC/1mA
Efficiency: Up to 83% Custom Design Availbale
Output Shor t Circuit Condition
Overvoltage protection Thermal Shutdown Protection
Ripple&noise(20MHz Band Width): 50mVp-p
Operation Temperature: -40~+80°C
RoHS compliant
MTBF > 1000000Hrs
Products type:
|
model |
lnput Voltage |
Output |
|
||||
|
(VDC) |
(mA) |
(%) |
(%) |
(mV) |
Efficiency |
||
|
Voltage |
Current |
Line |
Load |
Ripple |
|
||
|
Vo1 |
lo1 |
Vo1 |
Vo1 |
Vo1(Typ) |
|
||
|
AC110S3.3-1W |
|
+3.3V |
303 |
±0.5 |
±1 |
50 |
69% |
|
AC110S05-1W |
+5V |
200 |
±0.5 |
±1 |
50 |
75% |
|
|
AC110S09-1W |
+9V |
111 |
±0.5 |
±1 |
50 |
78% |
|
|
AC110S12-1W |
+12V |
83 |
±0.5 |
±1 |
50 |
80% |
|
|
AC110S15-1W |
+15V |
67 |
±0.5 |
±1 |
50 |
81% |
|
|
AC110S24-1W |
+24V |
42 |
±0.5 |
±1 |
50 |
82% |
|
|
AC110S3.3-2W |
+3.3V |
600 |
±0.5 |
±1 |
50 |
69% |
|
|
AC110S05-2W |
+5V |
400 |
±0.5 |
±1 |
50 |
75% |
|
|
AC110S09-2W |
+9V |
222 |
±0.5 |
±1 |
50 |
78% |
|
|
AC110S12-2W |
+12V |
167 |
±0.5 |
±1 |
50 |
80% |
|
|
AC110S15-2W |
+15V |
133 |
±0.5 |
±1 |
50 |
82% |
|
|
AC110S24-2W |
+24V |
83 |
±0.5 |
±1 |
50 |
83% |
|
